ALFA C+ FIELD SPRAYING MACHINE

ALFA C+ Field Sprayer

ALFA C+ Field Sprayer, the tank capacity is 600,800,1000,1300 liters. Cereals, corn, beets, pulses, cotton etc. It is used for pest control of plants. Various types of sprayers are available according to spraying requirements. Its compact design, hydrostatic and hydraulic system allow it to spray easily and effectively. ALFA C+ Field Sprayer is specially designed for wider product range and scope to spray all kinds of pesticides, herbicides and fungicides. It can also be used to disinfect poultry houses and barns.

Features	Unit	ALFA C+ 6	ALFA C+ 8	ALFA C+ 10	ALFA C+ 13
Product code		ALFACY0601	ALFACY0801	ALFACY01001	ALFACY01301
Warehouse Material		Polietilen	Polietilen	Polietilen	Polietilen
Tank Liter	It	600	800	1000	1300
Pump Model	Piston Membranlı	Önallar C96	Önallar C96	Önallar C96	Önallar C96
Pump Flow	1/dk	96	96	96	96
Pump Pressure	Bar	50	50	50	50
Control Panel		OSR50-5	OSR50-5	OSR50-5	OSR50-5
Working Width	m	16	16	16	16
Nozzle Type		Conical Jet Brass	Conical Jet Brass	Conical Jet Brass	Conical Jet Brass
Number of Nozzles	Adet	33	33	33	33
Distance Between Nozzles	cm	50	50	50	50
Spraying Arm Height Adjustment		Hidrolik	Hidrolik	Hidrolik	Hidrolik
Spraying Arm Folding Adjustment		Manuel	Manuel	Manuel	Manuel
Tractor Power Required	BG	50	50	50	50
Working Cycle	dev/dk	540	540	540	540
Weight	kg	625	642	651	670
Most	cm	272	272	272	272
Width	cm	265	265	265	265
Height	cm	220	220	220	220
Truck Loading Quantity	adet	5	5	5	5
Number of Truck Loads	adet	11	11	11	11
20 Container Loads	adet	6	6	6	6
40 Container Loads	adet	13	13	13	13
