DELTA D FULL HYDRAULIC FIELD SPRAYER

Delta D Hydraulic Field Sprayer is offered with 400, 600, 800 and 1000 liter options. It is also used to combat harmful insects and diseases that can infect plants. It can be used in the cultivation of plants such as corn, cereals, pulses. With Delta D Hydraulic Field Sprayer, spraying the plant is provided easily and effectively. Our Delta D Hydraulic Field Sprayer machine is under warranty for 2 years. Delta D Hydraulic Field Sprayer is specially designed and suitable for all liquid pesticides.

Features	Unit	DELTA D 4	DELTA D 6	DELTA D 8	DELTA D 10
Product code		DELTAD0401	DELTAD0601	DELTAD0801	DELTAD01001
Warehouse Material		Polietilen	Polietilen	Polietilen	Polietilen
Tank Liter	It	400	600	800	1000
Pump Model	Piston Membranlı	Önallar C96	Önallar C96	Önallar C96	Önallar C96
Pump Flow	1/dk	96	96	96	96
Pump Pressure	Bar	50	50	50	50
Control Panel		OSR50- 5	OSR50- 5	OSR50- 5	OSR50- 5
Working Width	m	15	15	15	15
Nozzle Type		Fan Jet Brass	Fan Jet Brass	Fan Jet Brass	Fan Jet Brass
Number of Nozzles	Adet	30	33	33	33
Distance Between Nozzles	cm	50	50	50	50
Spraying Arm Height Adjustment		Hidrolik	Hidrolik	Hidrolik	Hidrolik
Spraying Arm Folding Adjustment		Hidrolik	Hidrolik	Hidrolik	Hidrolik
Tractor Power Required	BG	50	50	50	50
Working Cycle	dev/dk	540	540	540	540
Weight	kg	374	394	414	426
Most	cm	135	135	148	148
Width	cm	103	103	103	103
Height	cm	250	250	250	250
Truck Loading Quantity	adet	7	7	7	7
Number of Truck Loads	adet	12	12	12	12
20 Container Loads	adet	8	8	8	8
40 Container Loads	adet	16	16	16	16
